Centipede head

Unread post by Charles Krebs » 12.01.2008 09:10

These are images of fairly small centipedes that were found in moss samples. In both cases looking at the ventral side.

The upper image was taken with an Olympus 4/0.16 S Plan Apo, using darkfield illumination. The stack consisted of 19 images.

The lower image gives a good look at one of the articulated pincers. Brightfield illumination. Partially crossed polarization was used to show the internal musculature. This was taken with an Olympus 10/0.40 S Plan Apo. The stack consisted of 16 images.

An Olympus NFK 1.67X projection eyepiece and a Canon 350D were used on the trinocular tube.





User avatar
Dan Kozub
Posts: 355
Joined: 24.03.2004 18:14

Unread post by Dan Kozub » 14.01.2008 17:11

Charles, thanks for sharing these beautiful images!

genosmm
Posts: 1
Joined: 03.03.2008 23:31

Unread post by genosmm » 20.04.2008 21:03

Charles,

Nice Shots!

What are the sizes of the resulting files? Also what format do you normally store these stacked photos?

Gene OHara

Charles Krebs
Posts: 38
Joined: 06.04.2005 08:00
Contact:

Unread post by Charles Krebs » 01.05.2008 20:45

Gene,

The resulting image file has the same pixel dimensions as each of source images. For my microscope shots this is 3456x2304 pixels (Canon 350D), for my "macro" shots it is 3872x2592 (Nikon D200). I usually save everything as "tif" files to avoid any compression artifacts. Then, if they are to be posted online I'll resize and save as a separate "jpg" version.
